    Plastic Pipe Extrusion Line HDPE PE Pipe Making Machine For Water Supply

    Ask Lasest Price
    Brand Name : Wangyuan
    Model Number : pe pipe line
    Certification : SGS
    Price : 39999-48888usd
    Payment Terms : TT , L/C
    Supply Ability : 16 sets
    Delivery Time : 60 days
    • Product Details
    • Company Profile

    Plastic Pipe Extrusion Line HDPE PE Pipe Making Machine For Water Supply

    Single Screw extruder HDPE PE PP Pipe Making Extruding Plastic Extruder Pipe Machine

    PE HDPE pipe making machine HDPE pipe production machine line
    PE series plastic pipe production line is mainly used for producing pipe of water supply and drainage in the field of agriculture and construction cable etc. This machine consists of vacuum calibration tank,haul off unit,cutting unit,stacker etc . The single screw extruder and haul off unit apply famous A/C frequency conversion speed regulation device,both vacum pump and driving motor apply famous brand .The haul-off unit includes two-claw type,three-claw type,four-claw type,six-claw type,eight-claw type,ten-claw type,twelve-claw type etc.Dust fre cutting machine ,saw blade cutting machine or planetary cutting machine can be applied,the property of machine group is reliable.The production efficiency is high with special device,it can produce inner wall spiral pipe, inner wall hollow pipe ,and core layer foam pipe.It can also produce PP, PE, ABS, PPR, PERT, Silicon core pipe etc .The planetary cutting machine is controlled automatically with computer,it has such advantages of simple operation,reliable performance etc. It has reached international advanced level.

    Product Application

    1.The pipes are extruded by the first extruder and then enter the twist form machine, at the same time the basket co-extrusion mould forms pipes' shape.

    2.The pipes are based on high density PE as main raw material.


    Process line

    Raw material+master batches→mixing → vacuum feeding → material dryness → single screw extruder → basket co-extrusion mould → calibrator → spray vacuum calibration tank → spray cooling water tank → belt haul-off → single screw glue extruder → winder → winding roller forming → water cooler → pipe rack → finished product inspecting&packing


    Main advantage

    1.This kind of pipes have many advantages, such as corrosion resistant light, easy to fix, long time to use etc.
    2.The pipes are widely used in high-way, municipal constructional, flats and so on.

    Pipe Range(mm)
    Extruder Model
    Extruder power(kw)
    Max.output(kg/h)
    20-63
    65/33
    37
    120
    50-160
    75/33
    55
    200
    75-250
    75/33
    110
    330
    90-315
    75/33
    132
    380
    160-450
    90/33
    160
    450
    315-630
    120/33
    280
    750
    400-800
    150/33
    355
    900
    710-1200
    120/33
    280
    1200
    1000-1600
    120/33
    280
    1500
    Plastic Pipe Extrusion Line HDPE PE Pipe Making Machine For Water SupplyPlastic Pipe Extrusion Line HDPE PE Pipe Making Machine For Water SupplyPlastic Pipe Extrusion Line HDPE PE Pipe Making Machine For Water SupplyPlastic Pipe Extrusion Line HDPE PE Pipe Making Machine For Water SupplyPlastic Pipe Extrusion Line HDPE PE Pipe Making Machine For Water SupplyPlastic Pipe Extrusion Line HDPE PE Pipe Making Machine For Water Supply
