Product Description:
HDPE Spiral pipe extrusion line
HDPE CORRUGATED SPRIAL CONDUIT PIPE POST TENSIONING PRESSTRESSED
TUBE EXTRUSION MACHINE pe pipe making machine
PE HDPE Prestressed POST TENSION Concrete Strand Spiral TUBE carbon
Corrugated Pipe extrusion line
PE water supply pipe and gas pipe extrusion machine can produce either PE water supply pipe or Gas
pipe. We have 24 years of manufacturing large size HDPE pipe
extrusion machine line experience and exported to India, Indonesia,
Singapore, Vietnam, Middle east contries, Russia etc.
PE plastic pipe extrusion machine can produce a variety type of PE
pipe, which offers distinct advantages as a piping material: Light
weight | Flexibility |Chemical resistance |Overall toughness |
Longevity.
PE Prestressed Concrete Strand HDPE Spiral Corrugated Pipe
extrusion line
The benefits of the PE pipe out the Kingson Plastic extruder make it an ideal piping material for a broad
variety of applications such as potable water service or distribution lines, natural gas distribution, lawn sprinklers, sewers, waste disposal, and drainage lines. PE materials are generally resistant to most
ordinary chemicals.
Process flow of PP PE HDPE Extrusion Machine Plastic Pipe Lline:
Raw material + additive → mixing → vacuum feeding machine → hopper
dryer → single screw extruder → color code extruder → mould and
calibrator → vacuum forming machine → cooling tank → haul off
machine → cutting machine → discharging rack
Qingdao Cuishi Plastic Machinery has been dedicated to the
production of HDPE Spiral pipe extrusion line since 1999. We have SJ70,75,90 single screw extruder, which are
ideal machines for producing pipes with high output, stable quality
and advanced technology.Descriptions:
This extrusion line is mainly used for producing PE/HDPE carbon
spiral reinforced pipe. PE carbon spiral pipe production line is a
kind of plastic pipe equipment used to produce PE carbon spiral
pipe. The plastic pipe production line synthesizes and modifies
materials such as polyethylene and carbon, and is spirally formed
by an extrusion process. PE carbon spiral pipe It has the
advantages of PE plastic and carbon material, and has the
characteristics of flame retardancy, insulation, strong ring
stiffness, and good pressure resistance.
Application of the pipes:
PE carbon spiral pipe has a broad market application field, such
as: used in construction, chemical industry, miners, agricultural
irrigation, water conservancy, electric power and other fields,
especially in the current development of power infrastructure in my
country, a large number of wires and cables are buried in the
ground, carbon Plain spiral tube is an irreplaceable product.
Features:Single screw extruders especially used for polyolefine material
possess effective plasticizing effect and high extrusion speed.
• The special detachment type mixing screw and the standard
designed die with spiral structure & reasonable channel are
applicable to produce with smooth inside and outside face.
• All kind of polyolefine material, multi-layers spiral
strengthening pipe can be co-extruded for various uses, 80% of
recycle material can be used in production;
• Optimum spiral copper sizing sleeve, its entrance carrying
pre-cooling and powerful vacuum device to suit for high speed
extruding pipe.
• Specific design for spray cooling trough.
• Cooling water trough is made of stainless steel
• High efficient cooling comes from peculiar spraying nozzle and
high efficiency water pump.
• Three-dimensional regulation, longitudinal move by motor.
• Advanced co-extrusion technology and low cost to use recovery
material.
Description of PE Spiral Prestressed Pipe Making Machine:
Plastic Cable Protection Spiral Pipe Machine HDPE Spiral Pipe
Production Line MachineryQingdao Wings Plastic Technology Co., LTD.
The company is focusing on research and development of the
continuous production of
PE,PVC corrugated pipe production line manufacturing. The line
could produce spiral corrugated pipe by HDPE or PVC raw materials.
This kind of spiral corrugated pipe is high temperature resistance,
corrosion resistance, wear resistance, high strength, widely
used in bridge prestressed pipe, underground cable threading
sheath, etc.
The machine inclued: SJ - 70/30 type single screw extruder, die
head mold, forming machine, cutting machine, winder system or
stacking machine. Product material is PVC/PE, optimal pipe diameter
range for Φ 50-200 mm Φ. Simple operation, good integrity,
continuous and stable production, low noise, high efficiency, long
service life.
The spiral corrugated pipe product has special spiral physical
structure, the pipe material mechanical performance is good, the
compressive strength, pipe buried under deformation, inner spiral
uniform cable around the cooling efficiency and effectively
protect the security of the cable.
The company also offers a wide range of other plastic machinery
such as cable shealthing pipe machine and drainage pipe extrusion
machine. This highly efficient equipment is capable of producing
various sizes and shapes of HDPE Spiral pipe extrusion line in accordance to customer's requirements. The whole process is
automated from material feeding to finished product delivery,
ensuring maximum efficiency while minimizing labor costs.
With years of experience in the industry and excellent after-sales
service, Qingdao Cuishi Plastic Machinery provides customers with
reliable products that meet their demands for quality assurance at
competitive prices. Whether you need a small or large scale
project, our team will work closely with you to customize solutions
that fit your specific needs perfectly.
Equipment List| NO. | Description | QTY | Unit | remarks |
| 1 | SJ65/132 conical twin Screw Extruder | 1 | set | 30kw innovince servo motor |
| 2 | Die Head Mold | 1 | set | chrome inside |
| 3 | core bar and mouth mold | 1 | set | for each size nose |
| 4 | Forming Mould (60pairs) | 1 | set | 40cr, Nitriding |
| 5 | Pipe Forming Machine | 1 | set | air&water cooling |
| 6 | Pipe cutter machine | 1 | set | |
Round Flat HDPE/PVC Plastic Bridge Prestressed Post Tensioning
Corrugated Pipe machine extrusion line for Concrete
pp/pe/pvc spiral prestressed pipe extrusion line/extruder/plastic
machine
1. Spiral Prestressed Pipe Extrusion Line
2. Prestressed Pipe Extruder
3. Prestressed Pipe Plastic Machine
escription of HDPE Prestress plastic corrugated spiral pipe
production machine line :
1. single screw extruder especially used for polyolefine material
posses effective plasticizing effect and high extrusion speed .
The special detached type compounding screw an die head with spiral
structure &reasonable channel are applicable to produce pipes
with smooth inside and outside face .
unique calibration and cooling modes is a capable pf producing pipe
with diameter from diameter 50mm -200mm,production speed is up to
0.4~6m/min
